Feature:
*High speed at 200mm/s;
*Various interfaces USB/USB+LAN for option;
*Support 58/80mm paper width
*LED directly shows printer status
*Easy paper loading, Easy operation and maintenance;
*Support network monitoring, and network printing;
*Support various Windows OS, Linux and OPOS driver;
*Support paper out detection, black mark detection;
*Compatible with EPSON ESC/POS command
Application:
*Lottery--- tickets
*Food-- Animal Tracing/Food Safety
*Meter reading-- Water/Electricity meter reading
*Insurance-- Vehicle insurance for onsite damage and loss assessment
*Warehousing-- Inventory Management/Goods Delivery & Receiving & Picking
*Parking-- Parking time and fee proof
*Logistic-- Express invoice/delivery order
*Mobile sales-- Invoice & Receipts infield service
*Law enforcement/Policing--Traffic/city inspectors/commerce/health supervision
Speficiation:
Item | RG-P80C |
Print Method | Direct thermal line |
Print Speed | 200mm/sec |
Effective Print Width | 72mm |
Font | Dot Density 576 dot/line or 512 dot/line Character Size ANK Character FontA:12*24, FontB:9*17, 24*24 Barcode 1-D:UPCA/UPCE/JAN13(EAN13)/JAN8(EAN8/CODE39/ITF/CODABAR/ CODE93/CODE1282-D: QR Code, PDF417 |
Print Paper | Paper Type Thermal paper Paper Width 57.5±0.5mm/79.5±0.5mm Outer Diameter 80mm(Max.) Paper Thickness 0.06~0.08mm Loading Method Drop-in easy paper loading |
Reliability | Print Head 100km Auto Cutter 1,500,000 times |
Print Command | Compatible with ESC/POS, EPSON, SAMSUNG |
Driver | Win9X/WinME/Win2000/WinNT/WinXP/WinVista/Win7/Win8/Linux/OPOS |
Interface | Serial+USB /Serial+USB+wifi/ Serial+USB+Blue tooth |
Power Adaptor | DC 24V/2A |
Cash Drawer Power | DC12V/1A |
Auto Cutter | Full or Partial Cut |
Physical parameters | Net Weight 1.2kg Dimension 179*152*118mm Color Black |
Operating Temp | 0~50°C |
Storage Temp | -20-60℃ |
Operating Humidity | 10~80% |
Storage Humidity | 10%-90%(No condensation) |
