Feature:
Features:
*Extremely compact and smart design;
*Flexible placement, front and up side paper exit;
*Innovative structure to ensure cutter jam free;
*Easy paper loading, Easy operation and maintenance;
*High speed at 300mm/s; *Printing space saving to reduce paper cost;
* Support 58/80/83mm paper width, 83mm diameter big paper roll;
*LED directly shows printer status;
*Auto paper partial cutting support;
*Various interfaces USB/Serial/LAN/Bluetooth/wifi for option;
*Compatible with ESC/POS command;
*Support various Windows,Linux and OPOS driver;
*Support Windows/Android/iOS Demo&SDK
Application:
*Lottery--- tickets
*Food-- Animal Tracing/Food Safety
*Meter reading-- Water/Electricity meter reading
*Insurance-- Vehicle insurance for onsite damage and loss assessment
*Warehousing-- Inventory Management/Goods Delivery & Receiving & Picking
*Parking-- Parking time and fee proof
*Logistic-- Express invoice/delivery order
*Mobile sales-- Invoice & Receipts infield service
*Law enforcement/Policing--Traffic/city inspectors/commerce/health supervision
Specification:
| Print Method | Direct thermal line |
| Effective Print Width | 48mm/72mm/80mm |
| Print Speed | 300mm/s(max.) |
| Font | Dot Density: 384dot/line or 576 dot/line or 640dot/line(max.) Character Size: ANK Character Font A:12*24,Font B:9*17 Barcode: 1D:UPCA/UPCE/JAN13(EAN13)/JAN8(EAN8/CODE39/ITF/CODABAR/CODE93/CODE128 2-D: QR Code, PDF417 |
| Paper Type | Thermal paper |
| Paper Width | 57.5±0.5mm(optional by a paper limiter)/79.5±0.5mm/82.5±0.5mm |
| Outer Diameter | 83mm(max.) |
| Paper Thickness | 0.06~0.08mm |
| Reliability | Print Head 150km Auto cutter 2,000,000 times |
| Print Command | Compatible with ESC/POS, EPSON |
| Driver | Win9X/WinME/Win2000/WinNT/WinXP/WinVista/Win7/Win8/Linux/OPOS |
| Interface | Serial+USB / USB+Bluetooth/ USB+wifi/ USB+LAN |
| Power Supply | DC24/2.5A |
| Dimension | 133*126*130mm |
| Net Weight | 1.2kg(without paper roll) |
| Operating Temp | 0~50°C |
| Storage Temp | -20-60℃ |
| Operating Humidity | 10~80% |
| Storage Humidity | 10%-90%(No condensation) |
