Features:
*High speed at 200mm/s;
*Various interfaces USB/USB+LAN for option;
*Support 58/80mm paper width
*LED directly shows printer status
*Easy paper loading, Easy operation and maintenance;
*Support network monitoring, and network printing;
*Support various Windows OS, Linux and OPOS driver;
*Support paper out detection, black mark detection;
*Compatible with EPSON ESC/POS command
Applications:
*Lottery--- tickets
*Food-- Animal Tracing/Food Safety
*Meter reading-- Water/Electricity meter reading
*Insurance-- Vehicle insurance for onsite damage and loss assessment
*Warehousing-- Inventory Management/Goods Delivery & Receiving & Picking
*Parking-- Parking time and fee proof
*Logistic-- Express invoice/delivery order
*Mobile sales-- Invoice & Receipts infield service
*Law enforcement/Policing--Traffic/city inspectors/commerce/health supervision
Speficiations:
| Print Method | Direct thermal line |
| Print Speed | 200mm/sec |
| Effective Print Width | 72mm |
| Font | Dot Density | 576 dot/line or 512 dot/line |
| Character Size | ANK Character FontA:12*24, FontB:9*17, 24*24 |
| Barcode | 1-D:UPCA/UPCE/JAN13(EAN13)/JAN8(EAN8/CODE39
/ITF/CODABAR/CODE93/CODE128
2-D: QR Code, PDF417 |
| Print Paper | Paper Type | Thermal paper |
| Paper Width | 57.5±0.5mm/79.5±0.5mm |
| Outer Diameter | 80mm(Max.) |
| Paper Thickness | 0.06~0.08mm |
| Loading Method | Drop-in easy paper loading |
| Reliability | Print Head | 100km |
| Auto Cutter | 1,500,000 times |
| Print Command | Compatible with ESC/POS, EPSON, SAMSUNG |
| Driver | Win9X/WinME/Win2000/WinNT/WinXP/WinVista/Win7/Win8/Linux/OPOS |
| Interface | Serial+USB /Serial+USB+wifi/ Serial+USB+Bluetooth |
| Power Adaptor | DC 24V/2A |
| Cash Drawer Power | DC12V/1A |
| Auto Cutter | Full or Partial Cut |
| Physical parameters | Net Weight | 1.2kg |
| Dimension | 179*152*118mm |
| Color | Black |
| Operating Temp | 0~50°C |
| Storage Temp | -20-60℃ |
| Operating Humidity | 10~80% |
| Storage Humidity | 10%-90%(No condensation) |
